技術參數Technical parmeters |
BJX1531 |
|
最大剪切長度Max.lenght of shearing |
3100mm |
|
最大剪切（薄木疊）Max.thickness for the pile of veneers |
60mm |
|
最大剪切寬度Max.width of shearing |
700mm |
|
電機 |
主電機Motors main motor |
YEJ112M-4 4kw |
|
定位機構電機Positioning motor |
JWH7138 370w |
|
液壓系統壓力Pressure of hydraulic system |
3Mpa |
|
進給定位推板電子計數器示值Positioning readings on cyber counter |
0-700mm |
|
光電保護器Infraerd proterctor |
1對 |
|
激光標線器Line laser maker |
2個 |
|
機床外形尺寸Overall dimensions(L*W*H) |
4275*1718*1556mm |
|
重量Weight |
3428kg |
